Arredigibot

DTG Pro A3 Printer

Parameter

Print Head: Epson PrecisionCore™ I3200 print heads.
Max Print Size:: 371*421mm Print Width.
Print Speed: 47 m²/h.

Feature

Arre Digibot's industry-leading technology and steadfast commitment to continuous innovation are designed to assist textile manufacturers in meeting the ever-increasing demands for environmental and economic sustainability. Aree Digibot's single- step direct-to-garments on-demand systems are known for their exceptional quality, vivid color accuracy, ease-of-use, and ability to allow textile printers to be profitable from the first impression. The ink with Softener solution to provide the smoothest hand feel and durability, as well as a cleaner, safer, and environmentally responsible manufacturing method.

Download Brochure

FEATURE OF DTG PRO

SUPER FAST BOOT

Fast bootin 5 minutes, start to work quickly, and cut down on waiting time, all with the goal of lowering costs for your company.

WHITE INK CIRCULATION & FILTRATION SYSTEM

Advanced white ink circulation & filtration system, prevent the white ink from solidifying, causing the nozzle to be blocked.

INTELLIGENT ALARM INK TANK THE SHORTEST TIME FROM FILE TO FINISHED GOODS

The cartridge alarm system is set up to protect the machine. It will automatically sound an alarm ifthe ink level falls below the set limit.

THE SHORTEST TIME FROM FILE TO FINISHED GOODS

Unique features and systems make it more cost effective and decrease or eliminate downtime, which leads to lost revenue.

Machine Parameter

Model	Arre Digitbot DTG-Pro
Printhead	I3200
Number of Nozzles	2pcs
Printing Accuracy	960*2400dpi
Printing Method	color, white
Printing Speed	47sqm/h
Equipment Weight	220kg
Printing Thickness	0-6mm
Printing Size	371*421mm
Print Mode	CMYK+W
Printing Software	Power Plotter7
Graphic Format	Tiff ,Jpg, Eps, Pdf, Png, AI, Psd
Voltage Power Supply	AC220/110 ±10，50HZ-60HZ, 150W
Working Environment	Temperature:20℃-28℃, Humidity:35℃-65℃
Ink Type	Paint Ink
Machine Size	1580mm1480mm620mm(Length * width * height)
Packing Size	980mm(L)650mm(W)770mm(H)
Packing Weight	84KG

FEATURES

Color accuracy-What you see on the screen is what you get on the print.
White mask generator-Easily create the white under-base to print on dark. Garments without depending on photo editing software programs.
Cost calculator-Preview the ink cost before printing.
Ease of use-Drag, drop and print, no special skills required.
White density configuration- Adjust the quantity of white ink and achieve different effects on the same print.
Compatible-Compatible with both Mac 0S and Windows.
Supports-Supports all common image file formats (.tif, gif,jpeg, png, .pdf).

Pre-treatment Machine For DTG Solution

Nozle	Single Nozzle(Imported From Usa)
Max Sprayed Area	410mmx540mm
Length Adjustable	0-540mm Range
Sprayed Fiux	13ml-80ml
Power	Ac110/200v,50hz/60hz, 150w
Machine Size: Machine Weight	850mm(L×550mm(W)×610mm(H) 55kg
Package Size: Package Weight	980mm(L)×650mm(W×780mm(H) 80kg

Some Application with Our DTG Solution

Whether you are a growing t-shirt printing business, already at high-production level or a screen printer looking towards hybrid apparel decoration, we have a perfect textile printing solution for you.
